Aclar® Barrier Films

Aclar Rx160 (0.60 Mil/15 μm)

Aclar® Rx160 is a 0.60 mil (15 µm) PCTFE homopolymer, high performance barrier film for the pharma and medical markets. It offers all the benefits of Aclar® where barrier considerations are less demanding.

Overview
Aclar® Rx160 is a 0.60 mil (15 µm) PCTFE homopolymer, high performance barrier film for the pharmaceutical and medical markets. It thermoforms well on conventional blister packaging equipment and offers all the benefits of Aclar where barrier considerations are less demanding. Aclar is a clear, poly-chloro-tri-fluoro-ethylene (PCTFE) pharmaceutical packaging film for blister packaging. With Aclar’s superior moisture barrier, your product is protected for worldwide distribution, including Zone 4 tropical locations. All Aclar fluoropolymer films comply with FDA regulation #21 CFR 177.1380, Drug Master File #1578.With Aclar film, you can dial in the exact properties you need from several product grades so you have the optimum balance of performance and economics. When you also need oxygen and/or light barrier protection, Aclar film can be laminated to a wide range of substrates.Honeywell has been supporting the pharmaceutical industry with Aclar film for more than 40 years.Aclar high and ultra-high barrier films are usually selected for the most demanding applications, such as high moisture sensitivity or the need to pass the accelerated stability trials as set forth by ICH.
Specifications

Properties

  • Crystalline Melting Point
    • 211 °C, ASTM D4591
    • 412 °F, ASTM D4591
  • Dimensional Stability
    • < -12% TD, 10 min at 300 °F/149 °C, ASTM D1204
    • <= +12 % MD, 10 min at 300 °F/149 °C, ASTM D1204
  • Elongation
    • 200 - 275% TD, ASTM D882
    • 80 - 130% MD, ASTM D882
  • Haze
    • < 1%, ASTM D1003
  • Modulus
    • 1241 - 1517 MPa TD Secant, ASTM D882
    • 1379 - 1655 Mpa MD Secant, ASTM D882
    • 180000 - 220000 psi TD Secant, ASTM D882
    • 200000 - 240000 psi MD Secant, ASTM D882
  • Specific Gravity
    • 2.11, ASTM D1505
  • Surface Tension
    • >= 42 dynes/cm (Treated Side), ASTM D2578
  • Tensile Strength
    • 11,000 - 17,000 psi MD, ASTM D882
    • 38 - 48 MPa TD, ASTM D882
    • 5,500 - 7,000 psi TD, ASTM D882
    • 76 - 110 MPa MD, ASTM D882
  • Water Vapor Transmission Rate
    • 0.0033 gms/100in²/day at 77 °F (25 °C), 60% RH, ASTM F1249
    • 0.006 gms/100in²/day at 86 °F (30 °C), 60% RH, ASTM F1249
    • 0.0062 gms/100in²/day at 86 °F (30 °C), 65% RH, ASTM F1249
    • 0.021 gms/100in²/day at 104 °F (40 °C), 75% RH, ASTM F1249
    • 0.027 gms/100in²/day at 100 °F (37.8 °C), 100% RH, ASTM F1249
    • 0.051 gms/m²/day at 77 °F (25 °C), 60% RH, ASTM F1249
    • 0.093 gms/m²/day at 86 °F (30 °C), 60% RH, ASTM F1249
    • 0.096 gms/m²/day at 86 °F (30 °C), 65% RH, ASTM F1249
    • 0.326 gms/m²/day at 104 °F (40 °C), 75% RH, ASTM F1249
    • 0.419 gms/m²/day at 100 °F (37.8 °C), 100% RH, ASTM F1249
  • Yield
    • 21896 in²/lb
    • 31.44 m²/kg

Notes

  • Test Conditions
    • Test conditions for properties are 73°F, 50% RH unless otherwise noted

Sampling

  • Sample Products
    • Yes

Properties

  • Crystalline Melting Point
    • 211 °C, ASTM D4591
    • 412 °F, ASTM D4591
  • Dimensional Stability
    • < -12% TD, 10 min at 300 °F/149 °C, ASTM D1204
    • <= +12 % MD, 10 min at 300 °F/149 °C, ASTM D1204
  • Elongation
    • 200 - 275% TD, ASTM D882
    • 80 - 130% MD, ASTM D882
  • Haze
    • < 1%, ASTM D1003
  • Modulus
    • 1241 - 1517 MPa TD Secant, ASTM D882
    • 1379 - 1655 Mpa MD Secant, ASTM D882
    • 180000 - 220000 psi TD Secant, ASTM D882
    • 200000 - 240000 psi MD Secant, ASTM D882
  • Specific Gravity
    • 2.11, ASTM D1505
  • Surface Tension
    • >= 42 dynes/cm (Treated Side), ASTM D2578
  • Tensile Strength
    • 11,000 - 17,000 psi MD, ASTM D882
    • 38 - 48 MPa TD, ASTM D882
    • 5,500 - 7,000 psi TD, ASTM D882
    • 76 - 110 MPa MD, ASTM D882
  • Water Vapor Transmission Rate
    • 0.0033 gms/100in²/day at 77 °F (25 °C), 60% RH, ASTM F1249
    • 0.006 gms/100in²/day at 86 °F (30 °C), 60% RH, ASTM F1249
    • 0.0062 gms/100in²/day at 86 °F (30 °C), 65% RH, ASTM F1249
    • 0.021 gms/100in²/day at 104 °F (40 °C), 75% RH, ASTM F1249
    • 0.027 gms/100in²/day at 100 °F (37.8 °C), 100% RH, ASTM F1249
    • 0.051 gms/m²/day at 77 °F (25 °C), 60% RH, ASTM F1249
    • 0.093 gms/m²/day at 86 °F (30 °C), 60% RH, ASTM F1249
    • 0.096 gms/m²/day at 86 °F (30 °C), 65% RH, ASTM F1249
    • 0.326 gms/m²/day at 104 °F (40 °C), 75% RH, ASTM F1249
    • 0.419 gms/m²/day at 100 °F (37.8 °C), 100% RH, ASTM F1249
  • Yield
    • 21896 in²/lb
    • 31.44 m²/kg

Notes

  • Test Conditions
    • Test conditions for properties are 73°F, 50% RH unless otherwise noted

Sampling

  • Sample Products
    • Yes
  • Haze : < 1%, ASTM D1003
  • Surface Tension : >= 42 dynes/cm (Treated Side), ASTM D2578
  • Elongation : 200 - 275% TD, ASTM D882|80 - 130% MD, ASTM D882
  • Dimensional Stability : < -12% TD, 10 min at 300 °F/149 °C, ASTM D1204|<= +12 % MD, 10 min at 300 °F/149 °C, ASTM D1204
  • Yield : 21896 in²/lb|31.44 m²/kg
  • Tensile Strength : 11,000 - 17,000 psi MD, ASTM D882|38 - 48 MPa TD, ASTM D882|5,500 - 7,000 psi TD, ASTM D882|76 - 110 MPa MD, ASTM D882
  • Modulus : 1241 - 1517 MPa TD Secant, ASTM D882|1379 - 1655 Mpa MD Secant, ASTM D882|180000 - 220000 psi TD Secant, ASTM D882|200000 - 240000 psi MD Secant, ASTM D882
  • Water Vapor Transmission Rate : 0.0033 gms/100in²/day at 77 °F (25 °C), 60% RH, ASTM F1249|0.006 gms/100in²/day at 86 °F (30 °C), 60% RH, ASTM F1249|0.0062 gms/100in²/day at 86 °F (30 °C), 65% RH, ASTM F1249|0.021 gms/100in²/day at 104 °F (40 °C), 75% RH, ASTM F1249|0.027 gms/100in²/day at 100 °F (37.8 °C), 100% RH, ASTM F1249|0.051 gms/m²/day at 77 °F (25 °C), 60% RH, ASTM F1249|0.093 gms/m²/day at 86 °F (30 °C), 60% RH, ASTM F1249|0.096 gms/m²/day at 86 °F (30 °C), 65% RH, ASTM F1249|0.326 gms/m²/day at 104 °F (40 °C), 75% RH, ASTM F1249|0.419 gms/m²/day at 100 °F (37.8 °C), 100% RH, ASTM F1249
  • Crystalline Melting Point : 211 °C, ASTM D4591|412 °F, ASTM D4591
  • Specific Gravity : 2.11, ASTM D1505
  • Test Conditions : Test conditions for properties are 73°F, 50% RH unless otherwise noted
  • Sample Products : Yes
