HydroBlock®
HydroBlock 22A 1500 I
HydroBlock® 22a I Series film is a PCTFE copolymer, high performance barrier film for industrial and electronics applications. It provides outstanding water vapor barrier and excellent chemical resistance with high clarity.
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
Specifications
General Information
- Application
- Electronics
- Performance Function
- Chemical Resistance
- Vapor Barrier
- Product Family
- 22A I Series Film
MD / TD
- Dimensional Stability
- ≤+15%/≤ -15%
- Elongation
- 125 - 200%/225 - 300%
- Modulus, Secant
- 150,000 -180,000 psi/150,000 -180,000 psi
- Tear Strength, Graves
- 1.4 lbf/1.4 lbf
- Tensile Strength
- 9,500 - 13,000 psi/6,000 - 8,000 psi
Physical Properties
- Thickness (mm)
- 1.5
- Water Vapor Transmission Rate
- 0.020 gms/100in2/day
- Yield
- 8,889 in2/lb
Sampling
- Sample Products
- Yes
General Information
- Application
- Electronics
- Performance Function
- Chemical Resistance
- Vapor Barrier
- Product Family
- 22A I Series Film
MD / TD
- Dimensional Stability
- ≤+15%/≤ -15%
- Elongation
- 125 - 200%/225 - 300%
- Modulus, Secant
- 150,000 -180,000 psi/150,000 -180,000 psi
- Tear Strength, Graves
- 1.4 lbf/1.4 lbf
- Tensile Strength
- 9,500 - 13,000 psi/6,000 - 8,000 psi
Physical Properties
- Thickness (mm)
- 1.5
- Water Vapor Transmission Rate
- 0.020 gms/100in2/day
- Yield
- 8,889 in2/lb
Sampling
- Sample Products
- Yes
- Performance Function : Chemical Resistance|Vapor Barrier
- Product Family : 22A I Series Film
- Application : Electronics
- Tear Strength, Graves : 1.4 lbf/1.4 lbf
- Dimensional Stability : ≤+15%/≤ -15%
- Tensile Strength : 9,500 - 13,000 psi/6,000 - 8,000 psi
- Modulus, Secant : 150,000 -180,000 psi/150,000 -180,000 psi
- Elongation : 125 - 200%/225 - 300%
- Yield : 8,889 in2/lb
- Water Vapor Transmission Rate : 0.020 gms/100in2/day
- Thickness (mm) : 1.5
- Sample Products : Yes
