Phosphorescent Pigments
Lumilux® Green SN-F2Y (50107)
Main use: safety signs, long afterglow products according to DIN 67510 at low lightning conditions, plastic, screen printing inks,
Overview
Lumilux SN-series are phosphorescent pigments that store energy when exposed to the sun or an artificial light source, and emit light long after the source has been removed. They are strontium aluminate-based, which feature significantly higher initial brightness and longer afterglow periods than zinc-sulfide based products. They meet UL and CE safety standards.
Honeywell Lumilux™ pigments have been a mainstay of the safety and security industry for more than four decades, consistently meeting the everchanging landscape of rigorous brightness standards required in safety, signage and authentication applications.
We offer the industry’s largest portfolio of phosphorescent and fluorescent pigments and taggants that can be used in a wide variety of applications, including:
• Safety and signage
• Automated sorting processes
• Watch dials
• Injection-molded toys and novelty items
• Paints and coatings
• Authentication applications
• Other specialty applications
Specifications
General Information
- Compatibility
- Insoluble in alkalies, organic solvents and decomposed by acids and water
- Maximum Particle Size
- 28, PSD50
- 28, PSD50
- Product Type
- Luminescent/Phosphorescent Pigments Degrees Celsius
- Typical Uses
- Afterglow products for low lightning conditions
- Application
- Ink
- Plastic
- Paints
- Particle Texture/Size
- Middle (D50 20 - 30 µm)
Physical Properties
- Color
- Green
- Typical Afterglow Brightness
- 30 mcd/m2, DIN 67510, Part 1, 10 min
- 267 mcd/m2, DIN 67510, Part 1, 5 min
- Screen Analysis
- < 0.5 % oversized particles on 125 μm testing screen
- Luminance DIN 67510-1
- 25 mcd/m2 after 60 minutes
- 260 mcd/m2 after 10 minutes
- Brightness
- 260 after 10 minutes
- 25 after 60 minutes
- Unspecified
- Chemical Composition
- Strontium Aluminate
- Density
- 3.4 g/cm3
- Physical Form
- Powder
- Solubility
- Decomposes with water
- Particle Size Distribution
- < 28 μm, PSD50
- Phosphorescence Color
- Green
Standards & Approvals
- Food Contact Approval
- No
Safety Information
- Chemical Stability
- Decomposes with water
- Incompatible Materials
- Acids
- Water
General Information
- Compatibility
- Insoluble in alkalies, organic solvents and decomposed by acids and water
- Maximum Particle Size
- 28, PSD50
- 28, PSD50
- Product Type
- Luminescent/Phosphorescent Pigments Degrees Celsius
- Typical Uses
- Afterglow products for low lightning conditions
- Application
- Ink
- Plastic
- Paints
- Particle Texture/Size
- Middle (D50 20 - 30 µm)
Physical Properties
- Color
- Green
- Typical Afterglow Brightness
- 30 mcd/m2, DIN 67510, Part 1, 10 min
- 267 mcd/m2, DIN 67510, Part 1, 5 min
- Screen Analysis
- < 0.5 % oversized particles on 125 μm testing screen
- Luminance DIN 67510-1
- 25 mcd/m2 after 60 minutes
- 260 mcd/m2 after 10 minutes
- Brightness
- 260 after 10 minutes
- 25 after 60 minutes
- Unspecified
- Chemical Composition
- Strontium Aluminate
- Density
- 3.4 g/cm3
- Physical Form
- Powder
- Solubility
- Decomposes with water
- Particle Size Distribution
- < 28 μm, PSD50
- Phosphorescence Color
- Green
Standards & Approvals
- Food Contact Approval
- No
Safety Information
- Chemical Stability
- Decomposes with water
- Incompatible Materials
- Acids
- Water
- Compatibility : Insoluble in alkalies, organic solvents and decomposed by acids and water
- Maximum Particle Size : 28, PSD50|28, PSD50
- Product Type : Luminescent/Phosphorescent Pigments Degrees Celsius
- Typical Uses : Afterglow products for low lightning conditions
- Application : Ink|Plastic|Paints
- Particle Texture/Size : Middle (D50 20 - 30 µm)
- Color : Green
- Typical Afterglow Brightness : 30 mcd/m2, DIN 67510, Part 1, 10 min|267 mcd/m2, DIN 67510, Part 1, 5 min
- Screen Analysis : < 0.5 % oversized particles on 125 μm testing screen
- Luminance DIN 67510-1 : 25 mcd/m2 after 60 minutes|260 mcd/m2 after 10 minutes
- Brightness : 260 after 10 minutes|25 after 60 minutes|Unspecified
- Chemical Composition : Strontium Aluminate
- Density : 3.4 g/cm3
- Physical Form : Powder
- Solubility : Decomposes with water
- Particle Size Distribution : < 28 μm, PSD50
- Phosphorescence Color : Green
- Food Contact Approval : No
- Chemical Stability : Decomposes with water
- Incompatible Materials : Acids|Water
Brochure
Name
Description
File Size
Date
Size
Authentication Solutions Document Security
application/pdf 480.36 KB
9/7/2022
480.36 KB
Lumilux® portfolio includes cutting-edge solutions for currency, government documents, brand protection, safety, novelty applications, all reflecting longstanding, advanced expertise in security pigments, detection solutions.
application/pdf 1.87 MB
9/7/2022
1.87 MB
Data Sheet
Name
Description
File Size
Date
Size
Main use: Long afterglow products according to DIN 67510 part 4. Useable for: Solvent-based paints and inks, thermoplastics, thermosetting plastics. Law / regulation: European norm EN 71-3: Safety of toys - Part 3: Migration of certain elements.
application/pdf 60.34 KB
9/7/2022
60.34 KB
Name
Description
File Size
Date
Size
Authentication Solutions Document Security
480.36 KB
9/7/2022
480.36 KB
Main use: Long afterglow products according to DIN 67510 part 4. Useable for: Solvent-based paints and inks, thermoplastics, thermosetting plastics. Law / regulation: European norm EN 71-3: Safety of toys - Part 3: Migration of certain elements.
60.34 KB
9/7/2022
60.34 KB
Lumilux® portfolio includes cutting-edge solutions for currency, government documents, brand protection, safety, novelty applications, all reflecting longstanding, advanced expertise in security pigments, detection solutions.
1.87 MB
9/7/2022
1.87 MB
Name
Description
File Size
Date
Size
Authentication Solutions Document Security
480.36 KB
9/7/2022
Lumilux® portfolio includes cutting-edge solutions for currency, government documents, brand protection, safety, novelty applications, all reflecting longstanding, advanced expertise in security pigments, detection solutions.
1.87 MB
9/7/2022
Main use: Long afterglow products according to DIN 67510 part 4. Useable for: Solvent-based paints and inks, thermoplastics, thermosetting plastics. Law / regulation: European norm EN 71-3: Safety of toys - Part 3: Migration of certain elements.
60.34 KB
9/7/2022
Property
Value
Reference crit. to DIN 67510,part1
260/25-1700 -W-K
afterglow 5min(coat.200g/m2)
Min. 89 mcd/m²
afterglow 10min(coat.200g/m2)
Min. 53 mcd/m²
afterglow 60min(coat.200g/m2)
Min. 8 mcd/m²
particle size distribution 50 %
Max. 28 µm
