Phosphorescent Pigments
Lumilux® Effect MB Green SN (50077)
Main use: plastic extrusion, injection moulding
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Lumilux SN-series are phosphorescent pigments that store energy when exposed to the sun or an artificial light source, and emit light long after the source has been removed. They are strontium aluminate-based, which feature significantly higher initial brightness and longer afterglow periods than zinc-sulfide based products. They meet UL and CE safety standards.
Honeywell Lumilux™ pigments have been a mainstay of the safety and security industry for more than four decades, consistently meeting the everchanging landscape of rigorous brightness standards required in safety, signage and authentication applications.
We offer the industry’s largest portfolio of phosphorescent and fluorescent pigments and taggants that can be used in a wide variety of applications, including:
• Safety and signage
• Automated sorting processes
• Watch dials
• Injection-molded toys and novelty items
• Paints and coatings
• Authentication applications
• Other specialty applications
General Information
- Application
- Plastic
- CAS Number
- Not determined
- Grade
- Not determined
- Maximum Particle Size
- N/A
- Particle Texture/Size
- Coarse (D50 30 - 40 µm)
- Typical Uses
- Injection moulding
- Plastics extrusion
Physical Properties
- Brightness
- 290 after 10 minutes
- 40 after 60 minutes
- Unspecified
- Chemical Composition
- Ca. 60% Alkaline Earth Aluminate + 40 % Special Wax
- Color
- Yellow-green
- Density
- 0.6 g/cm3
- Luminance DIN 67510-1
- 290 mcd/m2 after 10 minutes
- 40 mcd/m2 after 60 minutes
- Melting Point/Range
- 120 to 150 °C
- Phosphorescence Color
- Green
- Physical Form
- Granular
Safety Information
- Chemical Stability
- No data available
- Incompatible Materials
- Acids
- Water
International Transportation
- Chemical Class
- No data available
General Information
- Application
- Plastic
- CAS Number
- Not determined
- Grade
- Not determined
- Maximum Particle Size
- N/A
- Particle Texture/Size
- Coarse (D50 30 - 40 µm)
- Typical Uses
- Injection moulding
- Plastics extrusion
Physical Properties
- Brightness
- 290 after 10 minutes
- 40 after 60 minutes
- Unspecified
- Chemical Composition
- Ca. 60% Alkaline Earth Aluminate + 40 % Special Wax
- Color
- Yellow-green
- Density
- 0.6 g/cm3
- Luminance DIN 67510-1
- 290 mcd/m2 after 10 minutes
- 40 mcd/m2 after 60 minutes
- Melting Point/Range
- 120 to 150 °C
- Phosphorescence Color
- Green
- Physical Form
- Granular
Safety Information
- Chemical Stability
- No data available
- Incompatible Materials
- Acids
- Water
International Transportation
- Chemical Class
- No data available
- Particle Texture/Size : Coarse (D50 30 - 40 µm)
- Maximum Particle Size : N/A
- Typical Uses : Injection moulding|Plastics extrusion
- Application : Plastic
- CAS Number : Not determined
- Grade : Not determined
- Phosphorescence Color : Green
- Luminance DIN 67510-1 : 290 mcd/m2 after 10 minutes|40 mcd/m2 after 60 minutes
- Chemical Composition : Ca. 60% Alkaline Earth Aluminate + 40 % Special Wax
- Melting Point/Range : 120 to 150 °C
- Physical Form : Granular
- Brightness : 290 after 10 minutes|40 after 60 minutes|Unspecified
- Density : 0.6 g/cm3
- Color : Yellow-green
- Incompatible Materials : Acids|Water
- Chemical Stability : No data available
- Chemical Class : No data available
