Phosphorescent Pigments
Lumilux® Effect Green N-F (50081)
Main use: Afterglow plastic sheets, screen printing inks, injection molding
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
Lumilux N-series products are phosphorescent pigments that store energy when exposed to the sun or an artificial light source, and emit light long after the source has been removed. They are zinc sulfide-based, and meet UL and CE safety standards.
Specifications
General Information
- Application
- Ink
- Plastic
- CAS Number
- Not determined
- Compatibility
- Insoluble in water, alkalies, organic solvents and decomposed by acids
- Grade
- Not determined
- Maximum Particle Size
- 38, PSD50
- Particle Texture/Size
- Coarse (D50 30 - 40 µm)
- Product Type
- Luminescent/Phosphorescent Pigments Degrees Celsius
- Typical Uses
- Ceramics
- Enamel
- Solvent-based paints and inks
- Thermoplastics
- Thermosetting plastics
- Water-based paints
Physical Properties
- Brightness
- 2.7 after 60 minutes
- 27 after 10 minutes
- 64 after 5 minutes
- Chemical Composition
- ZnS: Cu
- Color
- Yellow-green
- Density
- 4.1 g/cm3
- Luminance DIN 67510-1
- 2.7 mcd/m2 after 60 minutes
- 27 mcd/m2 after 10 minutes
- 64 mcd/m2 after 5 minutes
- Particle Size Distribution
- < 38 μm, PSD50
- pH
- > 11 of a waterbased slurry
- Phosphorescence Color
- Green
- Physical Form
- Powder
- Screen Analysis
- < 0.5% oversized particles on 100 μm testing screen
- Solubility
- Insoluble
- Solubility in Water
- Insoluble
Safety Information
- Chemical Stability
- No data available
- Incompatible Materials
- Strong acids
International Transportation
- Chemical Class
- No data available
General Information
- Application
- Ink
- Plastic
- CAS Number
- Not determined
- Compatibility
- Insoluble in water, alkalies, organic solvents and decomposed by acids
- Grade
- Not determined
- Maximum Particle Size
- 38, PSD50
- Particle Texture/Size
- Coarse (D50 30 - 40 µm)
- Product Type
- Luminescent/Phosphorescent Pigments Degrees Celsius
- Typical Uses
- Ceramics
- Enamel
- Solvent-based paints and inks
- Thermoplastics
- Thermosetting plastics
- Water-based paints
Physical Properties
- Brightness
- 2.7 after 60 minutes
- 27 after 10 minutes
- 64 after 5 minutes
- Chemical Composition
- ZnS: Cu
- Color
- Yellow-green
- Density
- 4.1 g/cm3
- Luminance DIN 67510-1
- 2.7 mcd/m2 after 60 minutes
- 27 mcd/m2 after 10 minutes
- 64 mcd/m2 after 5 minutes
- Particle Size Distribution
- < 38 μm, PSD50
- pH
- > 11 of a waterbased slurry
- Phosphorescence Color
- Green
- Physical Form
- Powder
- Screen Analysis
- < 0.5% oversized particles on 100 μm testing screen
- Solubility
- Insoluble
- Solubility in Water
- Insoluble
Safety Information
- Chemical Stability
- No data available
- Incompatible Materials
- Strong acids
International Transportation
- Chemical Class
- No data available
- Application : Ink|Plastic
- Grade : Not determined
- Typical Uses : Ceramics|Enamel|Solvent-based paints and inks|Thermoplastics|Thermosetting plastics|Water-based paints
- Particle Texture/Size : Coarse (D50 30 - 40 µm)
- Product Type : Luminescent/Phosphorescent Pigments Degrees Celsius
- Maximum Particle Size : 38, PSD50
- CAS Number : Not determined
- Compatibility : Insoluble in water, alkalies, organic solvents and decomposed by acids
- Solubility : Insoluble
- Phosphorescence Color : Green
- Color : Yellow-green
- Chemical Composition : ZnS: Cu
- Brightness : 2.7 after 60 minutes|27 after 10 minutes|64 after 5 minutes
- pH : > 11 of a waterbased slurry
- Physical Form : Powder
- Solubility in Water : Insoluble
- Luminance DIN 67510-1 : 2.7 mcd/m2 after 60 minutes|27 mcd/m2 after 10 minutes|64 mcd/m2 after 5 minutes
- Density : 4.1 g/cm3
- Particle Size Distribution : < 38 μm, PSD50
- Screen Analysis : < 0.5% oversized particles on 100 μm testing screen
- Incompatible Materials : Strong acids
- Chemical Stability : No data available
- Chemical Class : No data available
