Solstice® HFO Blends

Solstice® N13 - (R-450A)

Solstice® N13 (R-450A) is a nonflammable, reduced-GWP replacement for HFC-134a in medium-temp applications: heat pumps, air- and water-cooled chillers, district heating/cooling systems, vending machines/beverage dispensers, and CO2 cascade systems.

Overview
Solstice® N13 is a non-flammable, reduced GWP replacement for HFC-134a in medium temperature applications like heat pumps, air-cooled and water-cooled chillers, district heating and cooling systems, vending machines and beverage dispensers, CO2 cascade systems etc. Its GWP is 573 and is listed under the U.S. EPA's SNAP program to replace ozone-depleting substances.Search SDS Number in SDS Finder - 16417
Specifications

General Information

  • Application
    • Commercial Refrigeration
  • ASHRAE Number
    • R-450A
  • Brand
    • Solstice®
  • Contains
    • R-134a / R-1234ze
  • Glide
    • 0.9 °F
  • Linear Formula
    • R-134a / R-1234ze
  • Refrigerant Class
    • HFO Blend
  • Refrigerant Type
    • Zeotropic blend
  • Replaces
    • R-134a
  • Substitutes
    • R-134a
  • Typical Lubricant
    • POE

Physical Properties

  • Composition
    • 42% / 58%
  • Critical Density
    • 30.7 lb/ft³
  • Critical Pressure
    • 553.8 psia
  • Critical Volume
    • 0.033 ft³/lbm
  • Heat of Vaporization
    • 87.7
  • Liquid Density
    • 73.4 lb/ft³ at 77°F
    • 78.6 lb/ft³ at 32°F
  • Liquid Heat Capacity
    • 0.335 Btu/lb at 77 °F
  • Liquid Thermal Conductivity
    • 44.1 mBtu/h-ft at 77 °F
  • Liquid Viscosity
    • 130.5 μlb/ft-hr at 77 °F
  • Molecular Weight
    • 108.6
  • Vapor Density
    • 0.336
    • 1.8
  • Vapor Heat Capacity
    • 0.239 Btu/lb at 77 °F
  • Vapor Pressure
    • 84 psia at 77 °F hectopascal
  • Vapor Thermal Conductivity
    • 8.0 mBtu/h ft at 77 °F
  • Vapor Viscosity
    • 8.2 μlb/ft-hr at 77 °F

Temperature

  • Boiling Point/Range
    • -10.1 °F at 1 Atm
  • Critical Temperature
    • 220 °F

Safety & Environment

  • Global Warming Potential
    • 604
  • Ozone Depletion Potential
    • 0

Standards & Approvals

  • ASHRAE Safety Classification
    • A1
  • REACH Product Stewardship
    • Registered

General Information

  • Application
    • Commercial Refrigeration
  • ASHRAE Number
    • R-450A
  • Brand
    • Solstice®
  • Contains
    • R-134a / R-1234ze
  • Glide
    • 0.9 °F
  • Linear Formula
    • R-134a / R-1234ze
  • Refrigerant Class
    • HFO Blend
  • Refrigerant Type
    • Zeotropic blend
  • Replaces
    • R-134a
  • Substitutes
    • R-134a
  • Typical Lubricant
    • POE

Physical Properties

  • Composition
    • 42% / 58%
  • Critical Density
    • 30.7 lb/ft³
  • Critical Pressure
    • 553.8 psia
  • Critical Volume
    • 0.033 ft³/lbm
  • Heat of Vaporization
    • 87.7
  • Liquid Density
    • 73.4 lb/ft³ at 77°F
    • 78.6 lb/ft³ at 32°F
  • Liquid Heat Capacity
    • 0.335 Btu/lb at 77 °F
  • Liquid Thermal Conductivity
    • 44.1 mBtu/h-ft at 77 °F
  • Liquid Viscosity
    • 130.5 μlb/ft-hr at 77 °F
  • Molecular Weight
    • 108.6
  • Vapor Density
    • 0.336
    • 1.8
  • Vapor Heat Capacity
    • 0.239 Btu/lb at 77 °F
  • Vapor Pressure
    • 84 psia at 77 °F hectopascal
  • Vapor Thermal Conductivity
    • 8.0 mBtu/h ft at 77 °F
  • Vapor Viscosity
    • 8.2 μlb/ft-hr at 77 °F

Temperature

  • Boiling Point/Range
    • -10.1 °F at 1 Atm
  • Critical Temperature
    • 220 °F

Safety & Environment

  • Global Warming Potential
    • 604
  • Ozone Depletion Potential
    • 0

Standards & Approvals

  • ASHRAE Safety Classification
    • A1
  • REACH Product Stewardship
    • Registered
  • Application : Commercial Refrigeration
  • Substitutes : R-134a
  • Linear Formula : R-134a / R-1234ze
  • Contains : R-134a / R-1234ze
  • ASHRAE Number : R-450A
  • Replaces : R-134a
  • Typical Lubricant : POE
  • Refrigerant Type : Zeotropic blend
  • Refrigerant Class : HFO Blend
  • Glide : 0.9 °F
  • Brand : Solstice®
  • Liquid Viscosity : 130.5 μlb/ft-hr at 77 °F
  • Liquid Density : 73.4 lb/ft³ at 77°F|78.6 lb/ft³ at 32°F
  • Critical Pressure : 553.8 psia
  • Vapor Heat Capacity : 0.239 Btu/lb at 77 °F
  • Liquid Thermal Conductivity : 44.1 mBtu/h-ft at 77 °F
  • Critical Density : 30.7 lb/ft³
  • Vapor Thermal Conductivity : 8.0 mBtu/h ft at 77 °F
  • Heat of Vaporization : 87.7
  • Vapor Viscosity : 8.2 μlb/ft-hr at 77 °F
  • Critical Volume : 0.033 ft³/lbm
  • Vapor Pressure : 84 psia at 77 °F hectopascal
  • Molecular Weight : 108.6
  • Liquid Heat Capacity : 0.335 Btu/lb at 77 °F
  • Vapor Density : 0.336|1.8
  • Composition : 42% / 58%
  • Boiling Point/Range : -10.1 °F at 1 Atm
  • Critical Temperature : 220 °F
  • Global Warming Potential : 604
  • Ozone Depletion Potential : 0
  • REACH Product Stewardship : Registered
  • ASHRAE Safety Classification : A1
