Industrial Propellant
Solstice® Propellant
A climate-friendly alternative to HFCs and HCFCs, our Solstice® propellant offers performance similar to HFC-134a, and is a near drop-in replacement with only minimal changes required to formulations and equipment.
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
A climate-friendly alternative to HFCs and HCFCs, our Solstice® propellant offers performance similar to HFC-134a, and is a near drop-in replacement with only minimal changes required to formulations and equipment. With our low GWP propellant, aerosols are back in favor.
Specifications
General Information
- Application
- Propellant
- Spray foam Insulation
- ASHRAE Number
- 34
- Brand
- Solstice®
- Linear Formula
- CF3CH=CHF
- Synonyms
- HFO-1234ze (E), 1234ze(E), trans-1234ze
Physical Properties
- Expansion Ratio
- 247 at 1 ATM and 60 °F (15.6 °C) (Liquid to Gas)
- Heat of Gas
- 0.224 Cp at 15.6 °C, cal/g
- 0.224 Cp at 60 °F, BTU/lb
- Heat of Vaporization
- 195 KJ/g at BP
- 84 BTU/lb at BP
- Kauri-Butanol Value
- 12.5
- Liquid Density
- 1.17 grams/cc at 21.1 °C
- 9.96 lb/gal at 60 °F
- Liquid Expansion Coefficient
- 0.0017 at 60 °F (15.6 °C)
- Liquid Viscosity
- 0.171 cP at 100 °F (37.8 °C)
- Molecular Weight
- 114
- Solubility in Water
- 0.037 at 70 °F (21.1 °C)
- Solubility of Water
- 0.022 at 70 °F (21.1 °C)
- Specific Gravity
- 3.958 at 60 °F (15.5 °C)
- Specific Heat of Liquid
- 0.323 BTU/lb at 60 °F, at Cp
- 0.323 cal/g at 15.6 °C, at Cp
- Surface Tension
- 8.95
- Theoretical Heat of Combustion
- 10.1 KJ/g at 70 °F (21.1 °C)
- 4359 BTU/lb at 70 °F (21.1 °C)
- Vapor Pressure
- 10.1 bar g at 54.4 °C hectopascal
- 147 psig at 130 °F hectopascal
- 3.4 bar g at 21.1 °C hectopascal
- 49.5 psig at 70 °F hectopascal
- 6.2 bar g at 37.8 °C hectopascal
- 89.9 psig at 100 °F hectopascal
- Vapor Volume
- 0.25 per liter of liquid at 16.6 °C, m3
- 33.02 per gal of liquid at 60 °F, ft3
Temperature
- Autoignition Temperature
- 368 °C
- 694 °F
- Boiling Point/Range
- -19 °C at 1 ATM
- -2.2 °F at 1 ATM
- Flashpoint
- Non-Flammable
Standards & Approvals
- ASHRAE Safety Classification
- A2L
Other
- Other Notes
- performance similar to HFC-134a
General Information
- Application
- Propellant
- Spray foam Insulation
- ASHRAE Number
- 34
- Brand
- Solstice®
- Linear Formula
- CF3CH=CHF
- Synonyms
- HFO-1234ze (E), 1234ze(E), trans-1234ze
Physical Properties
- Expansion Ratio
- 247 at 1 ATM and 60 °F (15.6 °C) (Liquid to Gas)
- Heat of Gas
- 0.224 Cp at 15.6 °C, cal/g
- 0.224 Cp at 60 °F, BTU/lb
- Heat of Vaporization
- 195 KJ/g at BP
- 84 BTU/lb at BP
- Kauri-Butanol Value
- 12.5
- Liquid Density
- 1.17 grams/cc at 21.1 °C
- 9.96 lb/gal at 60 °F
- Liquid Expansion Coefficient
- 0.0017 at 60 °F (15.6 °C)
- Liquid Viscosity
- 0.171 cP at 100 °F (37.8 °C)
- Molecular Weight
- 114
- Solubility in Water
- 0.037 at 70 °F (21.1 °C)
- Solubility of Water
- 0.022 at 70 °F (21.1 °C)
- Specific Gravity
- 3.958 at 60 °F (15.5 °C)
- Specific Heat of Liquid
- 0.323 BTU/lb at 60 °F, at Cp
- 0.323 cal/g at 15.6 °C, at Cp
- Surface Tension
- 8.95
- Theoretical Heat of Combustion
- 10.1 KJ/g at 70 °F (21.1 °C)
- 4359 BTU/lb at 70 °F (21.1 °C)
- Vapor Pressure
- 10.1 bar g at 54.4 °C hectopascal
- 147 psig at 130 °F hectopascal
- 3.4 bar g at 21.1 °C hectopascal
- 49.5 psig at 70 °F hectopascal
- 6.2 bar g at 37.8 °C hectopascal
- 89.9 psig at 100 °F hectopascal
- Vapor Volume
- 0.25 per liter of liquid at 16.6 °C, m3
- 33.02 per gal of liquid at 60 °F, ft3
Temperature
- Autoignition Temperature
- 368 °C
- 694 °F
- Boiling Point/Range
- -19 °C at 1 ATM
- -2.2 °F at 1 ATM
- Flashpoint
- Non-Flammable
Standards & Approvals
- ASHRAE Safety Classification
- A2L
Other
- Other Notes
- performance similar to HFC-134a
- Brand : Solstice®
- ASHRAE Number : 34
- Synonyms : HFO-1234ze (E), 1234ze(E), trans-1234ze
- Application : Propellant|Spray foam Insulation
- Linear Formula : CF3CH=CHF
- Theoretical Heat of Combustion : 10.1 KJ/g at 70 °F (21.1 °C)|4359 BTU/lb at 70 °F (21.1 °C)
- Kauri-Butanol Value : 12.5
- Liquid Viscosity : 0.171 cP at 100 °F (37.8 °C)
- Liquid Expansion Coefficient : 0.0017 at 60 °F (15.6 °C)
- Molecular Weight : 114
- Liquid Density : 1.17 grams/cc at 21.1 °C|9.96 lb/gal at 60 °F
- Surface Tension : 8.95
- Solubility of Water : 0.022 at 70 °F (21.1 °C)
- Solubility in Water : 0.037 at 70 °F (21.1 °C)
- Expansion Ratio : 247 at 1 ATM and 60 °F (15.6 °C) (Liquid to Gas)
- Vapor Volume : 0.25 per liter of liquid at 16.6 °C, m3|33.02 per gal of liquid at 60 °F, ft3
- Vapor Pressure : 10.1 bar g at 54.4 °C hectopascal|147 psig at 130 °F hectopascal|3.4 bar g at 21.1 °C hectopascal|49.5 psig at 70 °F hectopascal|6.2 bar g at 37.8 °C hectopascal|89.9 psig at 100 °F hectopascal
- Specific Heat of Liquid : 0.323 BTU/lb at 60 °F, at Cp|0.323 cal/g at 15.6 °C, at Cp
- Heat of Vaporization : 195 KJ/g at BP|84 BTU/lb at BP
- Specific Gravity : 3.958 at 60 °F (15.5 °C)
- Heat of Gas : 0.224 Cp at 15.6 °C, cal/g|0.224 Cp at 60 °F, BTU/lb
- Boiling Point/Range : -19 °C at 1 ATM|-2.2 °F at 1 ATM
- Autoignition Temperature : 368 °C|694 °F
- Flashpoint : Non-Flammable
- ASHRAE Safety Classification : A2L
- Other Notes : performance similar to HFC-134a
Technical Note
Name
Description
File Size
Date
Size
SAMPLE FORMULATION: Gentle foam cleanser with high gloss, creamy texture, easy spreadability. Solstice® Propellant (HFO-1234ze(E)) breakthrough for aerosol-based products.
application/pdf 231.63 KB
10/31/2023
231.63 KB
Solstice® 1234ze, HFO-1234ze, 1234ze. Flammability Assessment (trans-1,3,3,3-tetrafluoroprop-1-ene) ultra-low GWP liquefied gas propellant. Class 2.2 (nonflammable) Liquefied Gas N.O.S
application/pdf 312.93 KB
10/31/2023
312.93 KB
Sales Sheet
Name
Description
File Size
Date
Size
Honeywell Aerosol Technologies. Solstice® Propellant Comparison with Common Propellants. Physical Properties and Regulatory Comparison.
application/pdf 188.27 KB
10/31/2023
188.27 KB
Brochure
Name
Description
File Size
Date
Size
Honeywell Solstice® Propellant aerosol technology used in personal and household care, to insect sprays and industrial uses, precision and electronics cleaners, spray paints.
application/pdf 258.48 KB
10/31/2023
258.48 KB
Data Sheet
Name
Description
File Size
Date
Size
Solstice® Propellant, nonflammable aerosol propellant ultra-low (GWP), very low photochemical reactivity. Trans-1,3,3,3-tetrafluoroprop-1-ene, aka HFO-1234ze. INCI tetrafluoropropene
application/pdf 232.36 KB
10/31/2023
232.36 KB
Case Study
Name
Description
File Size
Date
Size
Safety is critical for the mining environment. Solstice® Propellant vapor pressure profile produces safer, more environmentally friendly product to compete with HFC-134a or DME-based product.
application/pdf 583.71 KB
10/31/2023
583.71 KB
Upgrading to Honeywell Solstice® Propellant makes CAIG DeoxIT® Cleaners better and safer maximizing conductive efficiency of metal means fewer low voltage glitches in the field.
application/pdf 293.34 KB
10/31/2023
293.34 KB
Name
Description
File Size
Date
Size
Honeywell Solstice® Propellant aerosol technology used in personal and household care, to insect sprays and industrial uses, precision and electronics cleaners, spray paints.
application/pdf 258.48 KB
10/31/2023
258.48 KB
SAMPLE FORMULATION: Gentle foam cleanser with high gloss, creamy texture, easy spreadability. Solstice® Propellant (HFO-1234ze(E)) breakthrough for aerosol-based products.
application/pdf 231.63 KB
10/31/2023
231.63 KB
Safety is critical for the mining environment. Solstice® Propellant vapor pressure profile produces safer, more environmentally friendly product to compete with HFC-134a or DME-based product.
application/pdf 583.71 KB
10/31/2023
583.71 KB
Honeywell Aerosol Technologies. Solstice® Propellant Comparison with Common Propellants. Physical Properties and Regulatory Comparison.
application/pdf 188.27 KB
10/31/2023
188.27 KB
Upgrading to Honeywell Solstice® Propellant makes CAIG DeoxIT® Cleaners better and safer maximizing conductive efficiency of metal means fewer low voltage glitches in the field.
application/pdf 293.34 KB
10/31/2023
293.34 KB
Solstice® Propellant, nonflammable aerosol propellant ultra-low (GWP), very low photochemical reactivity. Trans-1,3,3,3-tetrafluoroprop-1-ene, aka HFO-1234ze. INCI tetrafluoropropene
application/pdf 232.36 KB
10/31/2023
232.36 KB
Solstice® 1234ze, HFO-1234ze, 1234ze. Flammability Assessment (trans-1,3,3,3-tetrafluoroprop-1-ene) ultra-low GWP liquefied gas propellant. Class 2.2 (nonflammable) Liquefied Gas N.O.S
application/pdf 312.93 KB
10/31/2023
312.93 KB
Name
Description
File Size
Date
Size
SAMPLE FORMULATION: Gentle foam cleanser with high gloss, creamy texture, easy spreadability. Solstice® Propellant (HFO-1234ze(E)) breakthrough for aerosol-based products.
231.63 KB
10/31/2023
Solstice® 1234ze, HFO-1234ze, 1234ze. Flammability Assessment (trans-1,3,3,3-tetrafluoroprop-1-ene) ultra-low GWP liquefied gas propellant. Class 2.2 (nonflammable) Liquefied Gas N.O.S
312.93 KB
10/31/2023
Honeywell Aerosol Technologies. Solstice® Propellant Comparison with Common Propellants. Physical Properties and Regulatory Comparison.
188.27 KB
10/31/2023
Honeywell Solstice® Propellant aerosol technology used in personal and household care, to insect sprays and industrial uses, precision and electronics cleaners, spray paints.
258.48 KB
10/31/2023
Solstice® Propellant, nonflammable aerosol propellant ultra-low (GWP), very low photochemical reactivity. Trans-1,3,3,3-tetrafluoroprop-1-ene, aka HFO-1234ze. INCI tetrafluoropropene
232.36 KB
10/31/2023
Safety is critical for the mining environment. Solstice® Propellant vapor pressure profile produces safer, more environmentally friendly product to compete with HFC-134a or DME-based product.
583.71 KB
10/31/2023
Upgrading to Honeywell Solstice® Propellant makes CAIG DeoxIT® Cleaners better and safer maximizing conductive efficiency of metal means fewer low voltage glitches in the field.
293.34 KB
10/31/2023
Product Number
SKU
Description
10640783
Solstice® Propellant ISO TANK
10640783
Solstice® Propellant ISO TANK
10640786
Solstice® Propellant 10LB/4.5KG NRC
10640786
Solstice® Propellant 10LB/4.5KG NRC
10643454
Solstice® Propellant 44lb/20kg cyl
10643454
Solstice® Propellant 44lb/20kg cyl
10644235
Solstice® Propellant 1700lb/771kg ton cyl
10644235
Solstice® Propellant 1700lb/771kg ton cyl
SKU
Description
10640783
Solstice® Propellant ISO TANK
10640783
Solstice® Propellant ISO TANK
10640786
Solstice® Propellant 10LB/4.5KG NRC
10640786
Solstice® Propellant 10LB/4.5KG NRC
10643454
Solstice® Propellant 44lb/20kg cyl
10643454
Solstice® Propellant 44lb/20kg cyl
10644235
Solstice® Propellant 1700lb/771kg ton cyl
10644235
Solstice® Propellant 1700lb/771kg ton cyl
